Turnkey Project Full Set Extraction Production Equipment For Sodium Alginate Work Flow Chart
Raw Material---Soak、Clean---Fixed Color---Digestion---Rinse、Filter---Flocculation、Bleach---Calcium Precipitation---Aidification---Squeeze Dry、Smash---Neutralization---Dry
Sodium Alginate is a natural polysaccharide extracted from seaweed. Here are several main application areas and their roles:
Food processing field: sodium alginate can be used as a food additive (stabilizer, thickener, emulsifier, etc.) to produce various foods such as candy, chocolate, jam, etc.
Textile industry: sodium alginate can be used for sizing to improve the wear resistance and wrinkle resistance of textiles.
Agricultural field: sodium alginate can be used as a fertilizer slow-release agent to control the release rate of fertilizers and improve their utilization efficiency.
Items |
TD-Z-1.0 |
TD-Z-2.0 |
TD-Z-3.0 |
TD-Z-6.0 |
TD-Z-8.0 |
TD-Z-10 |
Capacity |
1200 |
2300 |
3200 |
6300 |
8500 |
11000 |
Inner Tank Design Pressure (Mpa) |
0.09 |
|||||
Jacket Design Pressure (Mpa) |
0.3 |
|||||
Compressed Air Pressure (Mpa) |
0.6-0.7 |
|||||
Product In Dia (mm) |
400 |
400 |
400 |
500 |
500 |
500 |
Heating Area (m2) |
3.0 |
4.7 |
6.0 |
7.5 |
9.5 |
12 |
Condensing Area (m2) |
4 |
4 |
5 |
5 |
8 |
10 |
Cooling Area (m2) |
1 |
1 |
1 |
2 |
2 |
3 |
Filter Area (m2) |
3 |
3 |
3 |
5 |
5 |
6 |
Slag Discharge Dia (m2) |
800 |
800 |
800 |
1000 |
1000 |
1000 |
Steam Consumption (kg/h) |
245 |
325 |
345 |
645 |
720 |
850 |
Technology and Manufacturing
We are a Custom Sodium Alginate Extraction Production Line Manufacturers and Wholesale Sodium Alginate Extraction Production Line Suppliers .The company specializing in intelligent biological fermentation, intelligent plant (Chinese medicine, CBD) extraction, intelligent pharmaceutical engineering, natural food, energy saving and environmental protection and other fields of technology and intelligent engineering design, equipment manufacturing, supporting procurement, construction and installation, equipment Specialized biological and medical equipment innovation high tech enterprises with EPC/EPCM service engineering as the core of system integration and factory commissioning.
